Accessories & Options

Raised-height cabinet frame option for P4-100 and P4-150 dispensers. Increases overall cabinet height for installations where a taller service opening is required or where plumbing entry is from below at a higher elevation.

Raised-height cabinet frame option for the P4-200 dual-hose dispenser. Larger footprint variant to accommodate the P4-200 cabinet dimensions.

Factory-installed 2-inch receipt printer option for the P4 Series dispenser. Prints transaction receipts including volume, dollar amount, date, time, and pump ID. Required for public-access retail locations.

P4-Series Safety System. Knock-over protection for installation under dispenser. Requires elevated skid frame or dispenser pit. Fits P4-100 and P4-150.

Spring-driven hose retractor for P4 Series dispensers. Mounts to hose outlet side. Automatically retracts the dispensing hose after each transaction, reducing hose wear, trip hazards, and drive-over damage at high-traffic fueling sites. Requires final installation on site.

Gasguard GG20L LPG Autogas Nozzle, Latching, 1‑3/4″ ACME, with strainer and low handle pressure. The designed-for nozzle on the P4-200 dual-hose dispenser. Compatible with all P4 Series single-hose models. Price subject to change with currency exchange rate.

ELAFLEX Euro-Bayonet Style Nozzle, Quick Connect. Automatic shut-off LPG dispensing nozzle with vapor return connection. Compatible with all P4 Series dispenser models. Price subject to change with currency exchange rate.

Improved Euro K-15 connection with lighter pull weight on trigger and more robust construction with higher flow rate. Price subject to change with currency exchange rate.

Elax Premium Hose and Safety Pull-away kit with GG20-HSL ACME nozzle. 1‑3/4″ ACME connection. Flexible and abrasion resistant hose with strain relief and LPG Autogas nozzle. Price subject to change with currency exchange rate.

Elax Premium Hose and Safety Pull-away kit with ZVG2 / GG40HSL Euro K-15 nozzle. Euro K-15 connection for international autogas vehicle compatibility. Price subject to change with currency exchange rate.

Economy Station Electrical Control Panel, single phase, 3–5 HP motors. NEMA 4X enclosure, E-STOP. For use with cabinet-style dispensers and small pump systems. Built to order — must provide voltage and full load current.

Economy-series NEMA 4X control panel, single or three phase, 3–5 HP motors. Includes E-STOP, LOTO disconnect, motor starter, overload protection, dispenser and FMS circuit breakers, time delay relay, data disconnect relay. Pre-wired. 2 hose maximum. Built to order.

Full-size NEMA 4X control panel, 3 phase, 5–10 HP motors. Includes E-STOP, LOTO disconnect, motor starter, overload protection, dispenser and FMS circuit breakers, time delay relay, data disconnect relay. Pre-wired. 2 hose maximum. Built to order.

VFD Electrical Control Panel, single phase, 5–7.5 HP motors. NEMA 4/12 enclosure with thermostat and cooling fans. Includes VFD and associated controls, E-STOP, LOTO disconnect, motor starter, overload protection. Built to order.

OPW/Petrovend PV100 Basic Fuel Management System configured for P4-Series. 50 vehicle max (expandable to 250). PIN code entry with optional card or RFID. USB memory stick data transfer. With pedestal or wing bracket. Call for exact pricing on specific configurations.

ParaFLEET Fuel Management System for small fleets. Fully integrated into P4-Series dispensers. UL listed and NTEP Certified. Data download via USB or network connection with static IP for remote access.

Internal Valve Actuator System. PLC driven compressor, NEMA 4/12 enclosure, leak detection and warning lights, 2-gallon reservoir, self-maintaining. Larger capacity systems custom built to order.

Automatic Cylinder Fill Control for Fairbanks and Cardinal scales. Automatically stops fuel flow when scale arm rises. All Class 1, Division 1 listed components for hazardous areas.

Heater Kit, 24VDC cabinet install, solid state. For dispensers and electrical enclosures. Film/membrane/cartridge type with programmable thermostat, sealed fuse, and install kit.

Inline 3/4″ filter, 600 psi WP. Auto reset filter change indicator, activated charcoal element, drain port. For installation before or after meter/dispenser.

Inline 2″ filter, 600 psi WP. Auto reset filter change indicator, activated charcoal element, drain port. For installation downstream of pump.

Hybrid Generator/Solar Integrated Station Power System. Powers dispenser and controls from solar or generator-charged 24VDC / 200AH battery pack with integrated charger/inverter. Automated generator start for battery charging and pump operation. Base model for 3.0 HP pump, 3 phase.
